Geoscience Australia Sentinel-2 Landsat Intertidal Calendar Year Collection 3


1.0.0 (Latest)

Product types:

Derivative, Raster

Time span:

2016 – 2022

Update frequency:


Product ID:




The DEA Intertidal product suite maps the changing elevation, exposure and tidal characteristics of Australia’s exposed intertidal zone, the complex zone that defines the interface between land and sea.

Incorporating both Sentinel-2 and Landsat data, the product suite provides an annual 10 m resolution elevation product for the intertidal zone, enabling users to better monitor and understand some of the most dynamic regions of Australia’s coastlines. Utilising an improved tidal modelling capability, the product suite includes a continental scale mapping of intertidal exposure over time, enabling scientists and managers to integrate the data into ecological and migratory species applications and modelling.

Access the data

For help accessing the data, see the Access tab.

See it on a map

See it on a map

Access the data on AWS

Get the data online

Download the data from ELVIS

Get the data online

Code examples

Code sample

GitHub repository

Code sample

Web Map Service (WMS)

Get via web service

Key details

Parent product(s)

Sentinel-2A and -2B and Landsat 7, 8, and 9 NBART and Observational Attributes 


Geoscience Australia Landsat Collection 3; Geoscience Australia Sentinel-2 Collection 3




Creative Commons Attribution 4.0 International Licence

Cite this product

Data citation

Bishop-Taylor, R., Phillips, C., Newey, V., Sagar, S.(2024). Digital Earth Australia Intertidal. Geoscience Australia, Canberra.


Bishop-Taylor, R., Sagar, S., Lymburner, L., Beaman, R.L., 2019. Between the tides: modelling the elevation of Australia’s exposed intertidal zone at continental scale. Estuarine, Coastal and Shelf Science. Available:

Sagar, S., Phillips, C., Bala, B., Roberts, D., Lymburner, L., 2018. Generating continental scale pixel-based surface reflectance composites in coastal regions with the use of a multi-resolution tidal model. Remote Sensing. 10, 480. Available:

Sagar, S., Roberts, D., Bala, B., Lymburner, L., 2017. Extracting the intertidal extent and topography of the Australian coastline from a 28 year time series of Landsat observations. Remote Sensing of Environment 195, 153-169. Available:


Intertidal environments contain many important ecological habitats such as sandy beaches, tidal flats, rocky shores, and reefs. These environments also provide many valuable benefits such as storm surge protection, carbon storage, and natural resources.

Intertidal zones are being increasingly faced with threats including coastal erosion, land reclamation (e.g. port construction), and sea level rise. These regions are often highly dynamic, and accurate, up-to-date elevation data describing the changing topography and extent of these environments is needed.

The intertidal zone also forms a critical habitat and foraging ground for migratory shore birds and other species. An improved characterisation of the exposure patterns of these dynamic environments is important to support conservation efforts and to gain a better understanding of migratory species pathways. However, this data is expensive and challenging to map across the entire intertidal zone of a continent the size of Australia.

The DEA Intertidal product suite provides annual continental-scale elevation and exposure product layers for Australia’s exposed intertidal zone, mapped at a 10 m resolution from DEA’s archive of open-source Landsat and Sentinel-2 satellite data. The exposed intertidal zone consists of coastal regions periodically inundated by tidal flows, not including areas obscured by vegetation cover such as mangroves. These intertidal products enable users to better monitor and understand some of the most dynamic regions of Australia’s coastlines.


  • Integration with existing topographic and bathymetric data to seamlessly map the elevation of the coastal zone.

  • Providing baseline elevation data to assist coastal hazard impact assessment from extreme weather and inundation events.

  • Investigating coastal erosion and sediment transport processes.

  • Supporting habitat mapping and modelling for coastal ecosystems extending across the terrestrial to marine boundary.

  • Characterise the spatio-temporal exposure patterns of the intertidal zone to support migratory species studies and applications.

Technical Information

DEA Intertidal features

The DEA Intertidal product suite contains 3 core product layers, 7 tidal attribute (ta) layers, and 2 quality assessment (qa) layers, all provided as continental 10 m resolution GeoTIFFs for the Australian coastal and intertidal region.

All datasets are produced annually from a 3-year composite of input data from the combined Sentinel-2 and Landsat 7, 8, and 9 DEA Collection 3 surface reflectance products. The product time series commences from 2016, with datasets labelled by the middle year of data. For example, the 2017 layer combines data from 2016, 2017, and 2018. Updates to the product suite are scheduled annually.

What this product offers

The DEA Intertidal product suite is the next generation of intertidal products developed in DEA. It improves on the DEA Intertidal Elevation Model (also known as the National Intertidal Digital Elevation Model or NIDEM) (Bishop-Taylor et al., 2019) and adds several new features and products to help users better understand the intertidal environment.

NIDEM was the first 3D model of Australia’s intertidal zone — the area of coastline exposed and flooded by ocean tides. The DEA Intertidal suite fundamentally changes and improves the way in which the exposed intertidal zone is modelled compared to the original NIDEM elevation model:

  • The addition of Sentinel-2 data improves the spatial resolution of the model to 10 m, compared to the 25m of the original NIDEM.

  • Incorporation of a new pixel-based method supports a reduction in the temporal epoch of the product to 3 years (in comparison to 28 years in NIDEM), improving the ability to capture the current state of dynamic coastal environments and enabling ‘change over time’ applications using annual epochs.

  • Quantification of the vertical uncertainty of the elevation model.

  • An Intertidal Exposure model at 10 m resolution to examine the spatiotemporal patterns of exposure and inundation across the intertidal zone, supporting migratory species studies and habitat mapping applications.

  • Tidal metrics to enable users to understand the varied ranges and distributions of tidal stages observed by the Landsat and Sentinel-2 satellites across Australia, and how this information can be used to better understand and interpret the products.

  • The implementation of an ensemble tidal modelling approach, acknowledging the wide range of global and regional tide models available and their varying performance across different regions of Australia. See Ensemble Tidal Modelling.

File Naming Convention

File names use the format:

{product_name}_{x tile code}{y tile code}_{year--frequency}_{dataset maturity}_{layer_name}.tif

For example:


Code repositories

Core Product Layers

DEA Intertidal Elevation



Data type



metres above MSL

DEA Intertidal Elevation (Figure 1) provides elevation in metre units relative to modelled Mean Sea Level for each pixel of the satellite-observed exposed intertidal zone across the Australian coastline. The elevation model is generated from DEA Landsat and Sentinel-2 surface reflectance data from each 3-year composite period, utilising a pixel-based approach based on Ensemble Tidal Modelling. For every pixel, the time series of surface reflectance data is converted to the Normalised Difference Water Index (NDWI) and each observation tagged with the tidal height modelled at the time of acquisition by the satellite. A rolling median is applied from low to high tide to reduce noise (such as white water, sunglint, and non-tidal water level variability), then analysed to identify the tide height at which the pixel transitions from dry to wet. This tide height represents the elevation of the pixel.

DEA Intertidal Elevation layer

Figure 1 — DEA Intertidal Elevation, with low elevation values shown in dark colours and high elevation shown in light colours.

DEA Intertidal Elevation Uncertainty



Data type




DEA Intertidal Elevation Uncertainty (Figure 2) provides a measure of the quality of each modelled elevation value in metre units. Uncertainty is calculated by assessing how cleanly the modelled elevation separates satellite observations into dry and wet observations. This is achieved by identifying satellite observations that were misclassified by the modelled elevation (for instance, pixels that were observed as wet at tide heights lower than the modelled elevation, or alternately, observed as dry at higher tide heights). The spread of tide heights from these misclassified observations is summarised using a robust Median Absolute Deviation (MAD) statistic, and reported as \(0.5 \times MAD\) to represent one-sided uncertainty bounds (i.e. ± uncertainty on either side of the pixel’s elevation). Common causes of high elevation uncertainty can be poor tidal model performance, rapidly changing intertidal morphology, or noisy underlying satellite data.

DEA Intertidal Elevation Uncertainty layer

Figure 2 — DEA Intertidal Elevation Uncertainty, with high uncertainty shown in light colours.

DEA Intertidal Exposure



Data type




‘No data’ value


DEA Intertidal Exposure (Figure 3) models the percentage of time that any intertidal pixel of known elevation is exposed from tidal inundation. Exposure is calculated by comparing the pixel elevation back against a high temporal resolution model of tide heights for that location, based on the Ensemble Tidal Modelling approach. Exposure percentage is calculated as the fraction of exposed observations relative to the total number of observations generated in the high temporal resolution tidal model for the 3-year product epoch.

DEA Intertidal Exposure layer

Figure 3 — DEA Intertidal Exposure, with low exposure values (i.e. rarely exposed pixels) shown in dark colours.

Tidal Attribute Layers (ta)

DEA Intertidal tidal spread



Data type




‘No data’ value


The tidal spread dataset provides the percentage of the full astronomical tidal range observed by the time series of satellite observations at each pixel (see Figure 4a). DEA Intertidal Spread takes the concept of satellite tide bias, introduced in Bishop-Taylor et al (2019), and applies it at a pixel scale to demonstrate the fraction of the full tide range that was sensor observed during the analysis epoch at that location. In this work, the astronomical tide range is defined as that modelled by the Ensemble Tidal Modelling approach.

DEA Intertidal low tide offset



Data type




‘No data’ value


The low tide offset dataset quantifies the proportion of the lowest tides not observed at any time during the analysis epoch by satellites at each pixel (as a percentage of the astronomical tide range). It is calculated by measuring the offset between the lowest astronomical tide (LAT) and the lowest satellite-observed tide (LOT; see Figure 4b). A high value indicates that DEA Intertidal datasets may not map the lowest regions of the intertidal zone.

DEA Intertidal high tide offset



Data type




‘No data’ value


The high tide offset dataset quantifies the proportion of the highest tides not observed at any time during the analysis epoch by satellites at each pixel (as a percentage of the astronomical tide range). It is calculated by measuring the offset between the highest astronomical tide (HAT) and the highest satellite-observed tide (HOT; see Figure 4c). A high value indicates that DEA Intertidal datasets may not map the highest regions of the intertidal zone.

Tidal Attributes Description Figure

Figure 4 — Illustration of the concept of observed tide heights (dots corresponding to satellite acquisition time) compared to the full modelled tidal range (blue lines). Descriptions of Spread (a), Lowtide offset (b), and Hightide offset (c) are detailed in the text.

DEA Intertidal lowest observed tide



Data type



metres above MSL

The lowest observed tide dataset maps the lowest satellite-observed tide (LOT) of the satellite time series at each pixel during the analysis epoch, based on Ensemble Tidal Modelling.

DEA Intertidal highest observed tide



Data type



metres above MSL

The highest observed tide dataset maps the highest satellite-observed tide (HOT) of the satellite time-series at each pixel during the analysis epoch, based on Ensemble Tidal Modelling.

DEA Intertidal lowest astronomical tide



Data type



metres above MSL

The lowest astronomical tide dataset maps the lowest astronomical tide (LAT) for each pixel, as modelled by the Ensemble Tidal Model for the analysis epoch. Note that the LAT modelled for each individual analysis epoch may differ from the LAT modelled across ‘all time’ for any given location.

DEA Intertidal highest astronomical tide



Data type



metres above MSL

The highest astronomical tide dataset maps the highest astronomical tide (HAT) for each pixel, as modelled by the Ensemble Tidal Model for the analysis epoch. Note that the HAT modelled for each individual analysis epoch may differ from the HAT modelled across ‘all time’ for any given location.

Quality Assessment Layers (qa)

DEA Intertidal NDWI frequency



Data type




‘No data’ value


This quality assessment band provides the inundation frequency of each pixel across the analysis epoch, as measured by NDWI. High values indicate that a pixel was observed as being inundated regularly in satellite observations.

DEA Intertidal NDWI correlation



Data type




This quality assessment dataset provides pixel-level Pearson correlations between NDWI satellite observations and tide heights from the Ensemble Tidal Model over the analysis epoch. High values indicate that patterns of inundation were positively correlated with tide, indicating that the pixel was likely to be tidally influenced.

Ensemble Tidal Modelling

The Ensemble Tidal Modelling approach was implemented to account for the varying performance and biases of 7 commonly used global tidal models when applied to the various regions and tidal regimes of continental Australia (Figure 5).

The tidal models listed below were implemented within the DEA environment using the pyTMD and DEA Tools Python packages:

  • FES2014 (Lydard et al., 2021)

  • FES2012 (Carrère et al., 2012)

  • TPXO8-atlas-v1 (Egbert & Erofeeva, 2002)

  • TPXO9-atlas-v5  (Egbert & Erofeeva, 2002)

  • EOT20 (Hart-Davis et al., 2021)

  • HAMTIDE11 (Taguchi et al., 2014)

  • GOT4.10 (Ray, 2013)

The ensemble process utilises ancillary data (in this case, the correlation of the NDWI values to each individual tidal model output) to weight and selects the top 3 tidal models for a given location. A single ensemble tidal output from these 3 optimal models is then generated for use in all downstream product workflows.

Ensemble tide validation Figure

Figure 5 — Global tide models validated at Australian Baseline Sea Level Monitoring Project (ABSLMP) and Global Extreme Sea Level Analysis (GESLA) tide gauges


The DEA Intertidal product suite extends the concepts developed in the DEA Intertidal Elevation (NIDEM) product, integrating higher resolution 10 m Sentinel-2 data with the original 30 m Landsat data to create annual elevation models and exposure product layers for Australia’s intertidal zone.

This shift to a more dynamic product suite is achieved through a pixel-based algorithm, replacing the waterline interpolation methods of NIDEM, and an improved tidal modelling process to better leverage the increased data resolution and density provided by the inclusion of Sentinel-2 data.

Processing Steps

  1. Satellite data from Sentinel-2A and -2B, Landsat 7, 8, and 9 are loaded.

  2. Satellite data cloud masked and converted to NDWI.

  3. Tides modelled for every satellite pixel using Ensemble Tidal Modelling.

  4. Satellite data filtered to probable intertidal pixels using NDWI inundation frequency and tide correlation and masked to remove deep ocean water using bathymetry from GA Australian 250m Bathymetry and Topography Grid (Beaman, 2023).

  5. Pixel-based rolling median applied from low to high tide.

  6. Intertidal elevation modelled based on tide height at which a rolling median transitions from dry to wet.

  7. Intertidal elevation uncertainty modelled based on how cleanly modelled elevation divides satellite observations into dry and wet.

  8. Intertidal exposure calculated by comparing Intertidal elevation against high frequency modelled tides.

  9. Tidal metrics calculated by comparing satellite-observed tides against high frequency modelled tides.


Beaman, R. 2023. AusBathyTopo 250m (Australia) 2023 Grid - A High-resolution Depth Model for Australia (20230004C). Geoscience Australia, Canberra.

Bishop-Taylor, R., Sagar, S., Lymburner, L., Beaman, R.J., 2019. Between the tides: Modelling the elevation of Australia’s exposed intertidal zone at continental scale. Estuarine, Coastal and Shelf Science 23, 115–128.

Carrère L., F. Lyard, M. Cancet, A. Guillot, L. Roblou, 2012. FES2012: A new global tidal model taking advantage of nearly 20 years of altimetry, Proceedings of meeting “20 Years of Altimetry”, Venice 2012

Egbert, G.D., Erofeeva, S.Y., 2002. Efficient Inverse Modeling of Barotropic Ocean Tides. J. Atmospheric Ocean. Technol. 19, 183–204.

Hart-Davis, M.G., Piccioni, G., Dettmering, D., Schwatke, C., Passaro, M., Seitz, F., 2021. EOT20: a global ocean tide model from multi-mission satellite altimetry. Earth System Science Data 13, 3869–3884.

Lyard, F.H., Allain, D.J., Cancet, M., Carrère, L., Picot, N., 2021. FES2014 global ocean tide atlas: design and performance. Ocean Science 17, 615–649.

Sagar, S., Roberts, D., Bala, B., Lymburner, L., 2017. Extracting the intertidal extent and topography of the Australian coastline from a 28 year time series of Landsat observations. Remote Sensing of Environment 195, 153–169.

Ray, R. D. (2013). Precise comparisons of bottom-pressure and altimetric ocean tides. Journal of Geophysical Research: Oceans, 118(9), 4570–4584.

Taguchi, E., Stammer, D., and Zahel, W. (2014), Inferring deep ocean tidal energy dissipation from the global high-resolution data-assimilative HAMTIDE model, J. Geophys. Res. Oceans, 119, 4573– 4592.


Product accuracy was validated against high resolution external Digital Elevation Model (DEM) data sources from across the Australian coastline, including aerial LiDAR and multibeam bathymetry datasets. These included datasets from the following sources:

  • Aerial LiDAR hosted on Geoscience Australia’s ELVIS platform

  • Aerial LiDAR and multibeam datasets hosted on the WA Bathymetry Portal

  • Aerial LiDAR over Gulf of Carpentaria tidal flats, Northern Territory Government

  • Aerial LiDAR over the Dampier Archipelago, University of Western Australia

  • Aerial LiDAR over Gulf of Carpentaria, Airborne Research Australia

To create a consistent basis for comparison against DEA Intertidal outputs, data from each validation data source was mosaicked and reprojected into 10 m DEM rasters. These rasters were then combined into annual continental-scale rasters corresponding to each year of data in the DEA Intertidal product suite. Because these DEMs had varied coverage of the intertidal zone due to being acquired across a range of tidal conditions, true exposed intertidal pixels were identified via a combination of manual digitisation using underlying high-resolution basemap data as a reference, and automated filtering to pixels with elevations between local Lowest and Highest Astronomical Tide. Additional areas of ocean or ‘no data’ contamination were masked using a simple slope rule, considering only pixels with a non-zero slope as viable candidates for intertidal pixels.

To evaluate the accuracy of DEA Intertidal Elevation, we calculated RMSE, MAE, correlation, bias, and R-squared statistics by comparing modelled DEA Intertidal Elevation outputs with validation data from the relevant year (e.g. 2021 DEA Intertidal Elevation data was compared against 2021 validation data). To provide insights into product performance across different coastal environments, this analysis was conducted separately on microtidal (tide range < 2 m), mesotidal (2–4 m) and macrotidal (> 4 m) coastlines (Table 1, Figure 6).

Table 1 — DEA Intertidal Elevation validation statistics comparing performance across microtidal, mesotidal, and macrotidal coastlines.












RMSE (m)




MAE (m)




Bias (m)








Validation at different tidal ranges

Figure 6 — DEA Intertidal Elevation validation heatmaps comparing performance across microtidal, mesotidal and macrotidal coastlines.

Caveats and limitations

  • DEA Intertidal covers the exposed intertidal zone which includes sandy beaches and shores, tidal flats and rocky shores and reefs. The model excludes intertidal vegetation communities such as mangroves.

  • Model performance improves with increasing tide range, being lowest in microtidal coastlines and highest in mesotidal and macrotidal coastlines. Due to the limited spatial extent of the intertidal zone in microtidal environments and the dominance of non-tidal water level influences (e.g. storm surge and ocean waves in high energy wave dominated environments), DEA Intertidal should be used with caution in microtidal environments.

  • DEA Intertidal relies on accurate tide modelling for reliable results. Although the Ensemble Tidal Modelling approach used in this product attempts to obtain the best local tide modelling data for any given location, areas of poor quality tide modelling still remain. This is particularly the case in areas of complex and unpredictable tide dynamics, such as embayments and estuaries where global ocean tide modelling results may produce highly inaccurate outputs. In these environments, modelled elevations and exposure should be used with caution and evaluated with reference to modelled elevation uncertainty data. Examples of areas affected by poor quality tide modelling inputs include:

    • Western Port, Victoria

    • Corner Inlet, Victoria

    • Broad Sound and Shoalwater Bay, Queensland

    • Van Diemen Gulf, Northern Territory

    • Torres Strait Islands, Queensland

  • Due to biases in the tidal coverage of satellite sensors like Landsat and Sentinel-2, DEA Intertidal outputs are unlikely to cover the full extent of the intertidal zone from Lowest to Highest Astronomical tide (e.g. Figure 5). These tidal biases can be evaluated using the product’s Tidal Attribute Layers which highlight regions where DEA Intertidal will underestimate the lower, upper or full extent of the intertidal zone.

  • Areas of false positive intertidal data over water exist in areas with low satellite coverage and high levels of environmental or sensor noise. Areas affected include:

    • Recherche Archipelago, Western Australia

    • South-eastern Eyre Peninsula, South Australia

    • Torres Strait Islands, Queensland

  • Areas of highly turbid water can be incorrectly mapped as intertidal terrain, particularly if temporal patterns of turbidity correlate with tidal dynamics. Areas affected by turbidity include:

    • King Sound, Western Australia

    • Cambridge Gulf, Western Australia

    • Joseph Bonaparte Gulf, Northern Territory

    • Daly River, Northern Territory

    • Broad Sound, Queensland

Quality Assurance

Code used to generate DEA Intertidal is run against automated integration tests to ensure that product quality is maintained as updates and improvements are made. These tests verify that the entire product generation workflow is performing as expected, and track changes in product accuracy over time.

Access the data

See it on a map

Learn how to use DEA Maps

Explore data availability

Learn how to use the DEA Explorer

Get the data online

Learn how to access the data via AWS

Code sample

Learn how to use the DEA Sandbox

Get via web service

Learn how to use DEA’s web services

How to explore DEA Maps

To explore DEA Intertidal on the interactive DEA Maps platform, visit the link below:

To add DEA Coastlines to DEA Maps manually:

  1. Open DEA Maps.

  2. Select Explore map data on the top-left.

  3. Select Sea, ocean and coast > DEA Intertidal > DEA Intertidal (Sentinel-2, Landsat)

  4. Click the Add to the map button on top-right.

View the product layer required by selecting the layer from the Styles dropdown menu, and use the Time selector to view the annual time-series of each product layer.

Note that the colour ramp for the Elevation and Elevation Uncertainty product layers is scaled dynamically from ‘low’ to ‘high’ to account for the wide variation of tidal ranges and elevations found across Australia, and provide the best contrast on the DEA Maps platform.

To query an absolute value for any of the product layers, click on a location to see a plain text summary of all the DEA Intertidal product suite data values at that pixel location.

How to access the data on AWS

To download DEA Intertidal data:

  1. Click the Access the data on AWS link above.

  2. Click on the ga_summary_grid_c3_32km_coastal.geojson file to download to your computer. This file can be used in a GIS package to identify the product tiles that you require for a given location. Alternatively, you can access this file via DEA Maps to identify required tiles (Sea, ocean and coast > DEA Intertidal > DEA Intertidal 32 km tile grid).

  3. Navigate to the required tile folder, first using the tile ‘x’ reference (e.g. x079) and then the tile ‘y’ reference (e.g. y123). Then select your year of interest.

  4. Click on the required product layer to download. See Technical Information for details on file naming and product layer details.

How to download data from ELVIS

To download the data from the ELVIS (Elevation Information System) platform, follow these steps.

  1. Open the ELVIS platform.

  2. Zoom in to your coastal area of interest on the ELVIS map.

  3. Click Order data on the top-right of the page.

  4. Select your desired selection method, then click Draw.

  5. Select your area of interest on the map, then click Search.

  6. In the Search Results menu (on the right side), locate the 10 Metre Intertidal DEM results and select the years of data you wish to order.

  7. Enter your industry and email address, then click Order dataset.

  8. Your data will be emailed to you as a zipped folder containing DEA Intertidal Elevation and Elevation Uncertainty GeoTIFF rasters.

Accessing DEA Intertidal on ELVIS

Accessing DEA Intertidal Elevation data on ELVIS

Old versions

View previous versions of this data product.

1.0.0: DEA Intertidal Elevation (Landsat)


The authors would like to sincerely thank the following individuals and organisations for validation data and valuable feedback on preliminary versions of this product:

  • Mick O’Leary/Ryan Lowe — University of Western Australia

  • Jenna Hounslow/Adrian Gleiss — Murdoch University

  • Mitchell Baum — University of Melbourne

  • Lucya Roncevich — Western Australia Department of Transport

  • Duncan Moore — GA Maritime Jurisdiction Advice

  • Ben Ford — Department of Climate Change, Energy, Environment and Water

  • Maria Zann — QLD Department of Environment and Science

  • Rob Beaman — James Cook University

  • Kathy Murray — WA Department of Biodiversity, Conservation and Attractions

  • Hannah Power — University of Newcastle

  • Mitch Lyons — University of New South Wales

  • Nick Murray — James Cook University

  • Airborne Research Australia

  • Northern Territory Government
